1766-L32BXBA

Overview

1766-L32BXBA is an Allen-Bradley MicroLogix 1400 controller with 32 I/O points, 24 VDC power supply, and multiple communication ports for industrial automation.

Identification

• Product ID: 1766-L32BXBA

• Model: MicroLogix 1400 Controller

• Type: Programmable Logic Controller

• Manufacturer: Allen-Bradley

Dimensions & Weight

• Weight: 0.79 kg (1.75 lbs)

I/O Data

• Total I/O points: 32

• Inputs: 12 fast 24 VDC, 8 normal 24 VDC, 2 analog voltage

• Outputs: 6 relay, 3 fast 24 VDC, 3 normal 24 VDC, 2 analog

• Channel count: 20 inputs, 12 outputs

• Input operating range: 0–24 VDC

• Relay output range: 5–125 VDC / 5–264 VAC

• Analog input range: 0–10 VDC, 1 LSB

Electrical Data

• Operating power: 24 VDC

• Inrush current: 15 A for 20 ms

• Operating frequency: 47–63 Hz

• Power consumption: 24 VDC, 15 A for 20 ms

Communication Interfaces

• Ports: 1 isolated RS232/RS485 combo, 1 non-isolated RS232, 1 Ethernet

• Supported protocols (serial): DF1, ASCII, MODBUS RTU, DNP3, DH485

• Supported protocols (Ethernet): Ethernet/IP, DNP3, MODBUS TCP/IP

Functional Features

• Memory: 20 KB

• Feature: Built-in RTC

---
