AIP504-50

Product Overview

The AIP504-50 is a high-reliability V-net Coupler Module designed for Yokogawa’s Distributed Control Systems (DCS), primarily used within the CENTUM CS 3000 and CENTUM VP families.

Technical Specifications

• Manufacturer: Yokogawa Electric Corporation
• Model: AIP504-50
• Module Type: V-net Coupler Module / Network Coupler Module
• Architecture Style: S1 standard design variant
• Communication Network: V-net / VL-net proprietary token-passing network
• Supported Speed: Up to 100 Mbps / 1 Gbps depending on backplane trunk configuration
• Nominal Power Input: 24 V DC supplied via system rack or bus
• Power Consumption: Approx. 20 W maximum depending on load
• Data Isolation: Electrical and optical isolation supported
• System Compatibility: CENTUM CS 3000, CENTUM VP, AFF500 Series Field Control Units
