6AV2124-1JC01-0AX0

Product Overview

6AV2124-1JC01-0AX0 is SIMATIC HMI KP900 Comfort 9" widescreen TFT display panel with key operation.

Technical Specifications

Display

• Type: TFT
• Screen diagonal: 9 in
• Width: 195 mm
• Height: 117 mm
• Number of colors: 16,777,216
• Resolution: 800 × 480 pixels
• Backlighting MTBF (at 25 °C): 80,000 h
• Backlight dimmable: 0–100 %

Control Elements

• Function keys: 26

Supply Voltage

• Type: DC
• Rated value: 24 V
• Permissible range: 19.2–28.8 V

Input Current

• Rated current: 0.75 A
• Starting current inrush I²t: 0.5 A²·s

Power

• Active power input (typ.): 18 W

Processor

• Type: X86

Memory

• Flash: Yes
• RAM: Yes
• Memory available for user data: 12 MB

---
