6GK5615-0AA00-2AA2

General Specifications

• Product type designation: SCALANCE S615 LAN Router

• Order number: 6GK5615-0AA00-2AA2

• Family: SCALANCE

• Description: LAN router for secure network communication

• Weight: Not specified

Transfer Rate

• Transfer rate: 10 Mbit/s, 100 Mbit/s

Interfaces – General

• Number of electrical/optical connections for network components or terminal equipment, max.: 5

Interfaces – Power Supply Connections

• Number of electrical connections for power supply: 1

• Number of electrical connections for redundant voltage supply: 1

• Type of electrical connection for power supply: 5-pole terminal block

Interfaces – Signal Inputs/Outputs

• Number of electrical connections for digital input signals: 1

• Number of electrical connections for digital output signals: 1

• Type of electrical connection for digital input signals: 2-pole terminal block

• Type of electrical connection for digital output signals: 2-pole terminal block

Storage Medium

• Design of removable storage (C-PLUG): Yes

Supply Voltage, Current Consumption and Power Loss

• Type of supply voltage: DC

• Supply voltage rated value: 24 V

• Supply voltage permissible range: 10.8 ... 28.8 V

• Current consumption at 24 V, typical: 0.2 A

• Power loss, rated value: 4 W

• Fusing at power supply input: Yes (non-replaceable melting fuse F 2 A5 / 32 V)

Ambient Conditions

• Ambient temperature during operation: -40 ... +70 °C

• Ambient temperature during storage: -40 ... +80 °C

• Ambient temperature during transport: -40 ... +80 °C

• Relative humidity at 25 °C without condensation during operation, max.: 95 %

• Protection class IP: IP20

Environmental Product Declaration

• Environmental Product Declaration: Yes

• Global Warming Potential (CO₂ eq) – total: 141.25 kg

• Global Warming Potential (CO₂ eq) – during manufacturing: 15.64 kg

• Global Warming Potential (CO₂ eq) – during operation: 125.19 kg

• Global Warming Potential (CO₂ eq) – after end of life: 0.42 kg

---
