6ES7515-2AM02-0AB0

Description

The Siemens 6ES7515-2AM02-0AB0 S7-1500 CPU is for industrial automation.

General Information

• Product Type Designation: CPU 1515-2 PN
• Hardware Functional Status: FS01
• Firmware Version: V2.9

Product Functions

• I&M Data: Yes (I&M0 - I&M3)
• Clock Synchronization Mode: Yes (6 cycles of 500 µs distributed, 1 ms centralized)

Bundled Software Packages

• STEP 7 TIA Portal: Configurable from V17 (FW V2.9)/V16 (FW V2.8), older versions can config as 6ES7515-2AM01-0AB0

Configuration Control

• Via Dataset: Yes

Display

• Screen Diagonal: 6.1 cm

Operating Elements

• Number of Buttons: 8
• Operating Mode Buttons: 2

Power Supply Voltage

• Voltage Type: 24 V DC
• Permissible Range: 19.2 V - 28.8 V
• Reverse Polarity Protection: Yes

CPU Processing Time

• Bit Operations: 30 ns
• Word Operations: 36 ns
• Fixed - Point Arithmetic: 48 ns
• Floating - Point Arithmetic: 192 ns

Dimensions

• Width: 70 mm
• Height: 147 mm
• Depth: 129 mm

Weight

• Approximate Weight: 830 g

---
