XBTF024610

The Schneider Electric XBTF024610, also cataloged as the XBTF024610 MAGELiS Graphic Operator Terminal, provides operator interaction through a TFT color LCD, dedicated function keys, and wired PLC communication interfaces. The terminal supports a 640 x 480 pixel resolution, 256 colors, an RJ45 Ethernet connector, and a 25-pin female SUB-D PLC serial port for operator interface and control-system data exchange.

Hardware Specifications

Parameter	Specification
Model	XBTF024610
Brand	Schneider Electric
Product Line	MAGELiS
Product Type	Graphic Operator Terminal
Weight	1.81 kg
Display Type	TFT Color LCD
Display Resolution	640 x 480 pixels
Color Support	256 colors
Front Panel Protection	IP65
Rear Panel Protection	IP20
Static Keys	12
Dynamic Keys	10
Service Keys	12
Alphanumeric Keys	12, plus 3 keys for alphabetical access
Ethernet Interface	RJ45 connector
PLC Serial Interface	25-pin female SUB-D connector

Operator Interface and Communication Architecture

The XBTF024610 combines a color display with physical operator keys for displaying process information and entering operator commands. Its 640 x 480 pixel display supports 256 colors for graphical process screens and equipment status visualization.

The RJ45 Ethernet interface and 25-pin female SUB-D serial interface provide physical connection points for communication with compatible control-system equipment. Network protocol support, serial communication parameters, and supported PLC models must be verified against the applicable Schneider Electric hardware documentation before system integration.

The front panel has an IP65 protection rating, while the rear panel is rated IP20. Installation must preserve the specified enclosure protection boundaries.

Frequently Asked Questions (FAQ)

Q: What display specifications does the XBTF024610 support?

A: It uses a TFT color LCD with a resolution of 640 x 480 pixels and supports 256 colors.

Q: Which physical communication interfaces are provided?

A: The terminal has an RJ45 Ethernet connector and a 25-pin female SUB-D PLC serial connector. Supported protocols and communication settings require verification against the applicable technical documentation.

Q: Can the XBTF024610 be installed in an enclosure exposed to dust or water?

A: The front panel is rated IP65, and the rear panel is rated IP20. The front panel rating applies to the properly installed front interface; the rear assembly requires an enclosure suitable for its protection requirements.

Field Installation Guidelines

• Panel mounting: Install the terminal in a compatible panel cutout and secure it according to the manufacturer's mechanical installation instructions.
• Environmental protection: Maintain the front panel sealing surface and gasket condition. Protect the rear assembly from dust and moisture consistent with its IP20 rating.
• Ethernet wiring: Connect the RJ45 interface to compatible network equipment using suitable industrial Ethernet cabling. Verify network configuration and protocol compatibility before commissioning.
• Serial wiring: Confirm the PLC serial pinout, electrical interface, cable type, and communication settings from the relevant hardware manuals before connecting the 25-pin SUB-D port.
• Grounding and EMC: Follow the manufacturer's protective grounding and electromagnetic compatibility requirements. Route communication cables separately from high-voltage and high-current switching conductors where practicable.
• Power connection: Verify the terminal's rated supply voltage, polarity, and current requirements from the manufacturer's documentation before energizing the unit.
• Commissioning: Check display operation, key response, communication status, and PLC data exchange before placing the terminal into service.

---
