DS200DCFBG1B

Product Overview

The DS200DCFBG1B is a Mark V Power Supply Board featuring 12 on‑board jumpers (13 for revision BKC or later), 7 DIP switches, and multiple connectors.

Jumpers & DIP Switches

• Configurable Jumpers: 12 on‑board (13 for revision BKC or later)
• DIP Switches: 7 for selection of application options

Indicators

• LEDs: 2 Red LEDs (CR51, CR55)
• Neon Light: 1 (LT1)

Testpoints

• Testpoints: 5 for voltage signals, board common, and ACCT signal status

Fuses

• Fuses: 3 (FU1, FU2, FU3) for power supply protection

Connectors

• Plug Connectors: 18
• Stab Connectors: 9

---
