2711-T10G3

Product Overview

The Allen‑Bradley 2711-T10G3 is a PanelView Standard operator terminal with a 10.1‑inch grayscale active matrix TFT display and touch input, designed for industrial HMI applications.

Display Specifications

• Display Type: Active Matrix Thin‑Film Transistor (TFT) with Cold Cathode Fluorescent (CCF) Backlight (4 shades of gray)
• Display Size: 10.1 in
• Display Color: Grayscale
• Display Area: 211 x 158 mm (8.3 x 6.2 in)
• Resolution: 640 x 480 pixels
• Backlight: 100,000 hr LED backlight life

Operator Input

• Input Type: Touch
• Touchscreen: 384 (24 columns x 16 rows)
• Touch Cell Size: 26 x 30 pixels

Memory

• Application Memory: 1008K bytes (application screens)

Communication

• Communication Ports: DH485; RS232 (printer)
• Communication: DH‑485 and Printer (RS‑232) Port

Power Specifications

• Input Voltage Range: 85‑264V AC, 47‑63 Hz
• Input Power: 85‑264 Volts AC
• Heat Dissipation: 39 W (132 BTU/HR)

Temperature

• Operating Temperature: 0‑55°C (32‑131°F)

Weight

• Weight: 7.06 lbs (3.20 kg)

---
