KJ3221X1-BK2

Overview

• Model: KJ3221X1-BK2

• Type: Analog Output (AO) Card, 8‑Channel, 4–20 mA with HART

• Series: S‑Series

• Manufacturer: Emerson

• Application: Provides analog output with HART capability for DeltaV control systems

Power Specification

• Local Bus Power: 12 VDC, 150 mA

• Bussed Field Power: 24 VDC, 300 mA

• Field Circuit: 24 VDC, 23 mA per channel

Environmental Specification

• Ambient Temperature: -40 to +70 °C

• Shock Resistance: 10 g, ½ sinewave for 11 ms

• Vibration Resistance:

  • 1 mm peak-to-peak from 2–13.2 Hz

  • 0.7 g from 13.2–150 Hz

• Airborne Contaminants: ISA‑S71.04‑1985 Class G3

• Relative Humidity: 5–95% non‑condensing

• Terminal Block Key Position: A4

---
