IS200TDBSH6ABC

Overview

General Electric IS200TDBSH6ABC Discrete Simplex Board is part of the Mark VI Turbine Control System Series. It provides discrete signal interfacing through large terminal blocks and integrated components, supporting reliable turbine control applications.

Basic Information

• Manufacturer: General Electric

• Series: Mark VI

• Product number: IS200TDBSH6ABC

• Type: Discrete Simplex Board

Components

• Rectangular black components: 12, arranged in 3 rows of 4

• Grey components: 2, positioned on either side of black components

• Capacitor: 1 solid yellow

Terminal Blocks

• Quantity: 2 (TB1, TB2)

• Color: Green

• Terminals per block: 48

Connectors

• Mid‑sized connector port: With multiple small female connections

---
