6AV6646-1AD22-0AX0

Product Overview

6AV6646-1AD22-0AX0 is a SIMATIC ITC2200 industrial thin client featuring a 21.5-inch widescreen TFT touch display and support for multiple remote communication protocols including RDP, VNC, SMARTSERVER, and web-based access.

Technical Specifications

• Display: 21.5-inch TFT widescreen display with LED backlight

• Resolution: 1920 × 1080 pixels (Full HD)

• Colors: 16.7 million colors

• Display Area: 495.6 mm × 292.2 mm

• Backlight: Dimmable LED, adjustable from 5% to 100%

• Backlight Lifetime: 30,000 hours (MTBF at 25°C)

• Touch Operation: Supported

• On-Screen Keyboard: Available

• Mounting Type: Panel-mounted device

• Supply Voltage: 24 V DC

• Voltage Range: 19.2 V DC to 28.8 V DC

• Maximum Current Consumption: 2.2 A

• Inrush Current (I²t): 0.5 A²·s

• Industrial Ethernet Ports: 1

• Ethernet Speed: Up to 1000 Mbit/s

• USB Ports: 2 rear USB interfaces

• Keyboard/Mouse Interface: USB

---
