Product Overview

The 51305482-505 is a High Level Analog Input (HLAI) Multiplexer Field Termination Assembly (FTA) engineered for Honeywell TDC 3000, TPS, and Experion PKS automation platforms.

Technical Specifications

Compatibility：

• Honeywell TDC 3000
• TotalPlant Solution (TPS)
• Advanced Process Manager (APM)
• High-Performance Process Manager (HPM)

Channels：Supports up to 32 multiplexed input channels

Input Signal Range：1 to 5 VDC    4 to 20 mA (via integrated precision resistors)

Power Requirement：24 VDC nominal, supplied through the I/O cabinet/base

Protection Features

Galvanic isolation for surge and noise suppression

Conformal coating (-505 suffix) for enhanced resistance to moisture, dust, and corrosive atmospheres

Environmental & Physical Characteristics

Operating Temperature: 0°C to 60°C (32°F to 140°F)

Storage Temperature: -40°C to 85°C (-40°F to 185°F)

Relative Humidity: 5% to 95% RH, non-condensing

Mounting: Standard FTA mounting channel or DIN rail

---
