CC-TROX01

Product Overview

CC-UPTA01-The Honeywell CC-UPTA01 is a single-channel universal pass-through adapter.

Technical Specifications

General Features

• Type: Single-channel pass-through adapter

• Compatibility: 2-wire AI/AO/DIL/DO/DOL, system-powered field I/O, HART pass-through

• Interface: Compatible with conventional Series C IOMs, Universal I/O, and Universal Safety IOM modules

Physical Dimensions

• Size: 118mm (D) × 85.75mm (W) × 10.0mm (H)

• Assembly Option: Backplane mount, screw-less

• Connections: 2 signal lines from safety system to field side

• Indicators: None

• Mistake Proof: Not applicable

Ambient Conditions

• Operating Temperature: -40°C to +70°C

• Storage/Transport Temperature: -40°C to +85°C

• Permissible Humidity: 5% to 95% (non-condensing)

• Vibration: Non-operational: 1g, 10Hz to 150Hz; Operational: 0.5g, 10Hz to 150Hz

• Shock: Operational: 5g; Non-operational: 15g

Enclosure and Mounting

• Assembly: Base plate and housing

• Mounting: Base plate with DIN rail mount and snap housing to the base plate

Electrical Specifications

• Power Voltage: 24VDC

• Maximum Current Rating: 500mA

• Power Indication: Not applicable

• Interface to Safety System: 37-pin DSUB (for SIC cable)

• Field Side Interface: Dedicated 3 terminals per channel

• Field Side Wire Gauge: 12–24 AWG

Product Type

---
