51309152-175

Product Overview

51309152-175 is an Analog Output (AO) module designed to provide multi-channel current output control with high accuracy and redundancy support.

Technical Specifications

Number of Channels: 8

IOP Configuration: AO

Output Current Range: 0.1–21.4 mA

Maximum Output Current: 26 mA

Resolution: ±0.05%

Calibrated Accuracy: ±0.35% (25°C, including linearity)

Output Ripple: 100 mV peak-to-peak at line frequency across 250 Ω load

Maximum Resistive Load: 750 Ω @ 22 mA

Redundancy: Yes, electrically isolated outputs with field-replaceable relay switching via FTA

Redundancy Bias: Yes

Smallest ORU: IOP

Humidity Range: 10–90% non-condensing

Surge Withstand Capability: ANSI/IEEE C37.90.1-1978

Conformal Coating: Yes, protective coating for corrosion resistance

---
