51305722-001

Product Overview

The 51305722-001 is a high-performance HLAI FTA, serving as the interface between field instruments and Honeywell DCS controllers for signal conditioning, protection, and routing.

Technical Specifications

System Compatibility: TDC 3000, Experion PKS, TPS Systems

Module Type: High Level Analog Input (HLAI) Field Termination Assembly (FTA)

Number of Channels: 16 Input Channels

Signal Range: 4 to 20 mA or 1 to 5 Vdc

Power Supply: 24 Vdc (Typically redundant inputs)

Mounting Type: Standard FTA Mounting Channel / DIN Rail

Conformal Coating: Yes (Protection against moisture and corrosive contaminants)

Isolation: Channel-to-channel and channel-to-ground isolation

---
