51305562-400

Product Overview

Technical Specifications

General & Physical Characteristics

• Dimensions: Standard Honeywell controller/file slot form factor
• Weight: Approximately 0.6 kg to 0.8 kg (1.3 to 1.8 lbs)
• Coating: Conformal coating for moisture, dust, and chemical protection in harsh environments

Electrical & Power Requirements

• Input Voltage: Supplied via standard Honeywell system backplane (typically 24V DC / 5V DC logic levels)
• Power Consumption: Optimized for low heat dissipation to extend service life in enclosed cabinets

Functional & Performance Specifications

• Compatibility: Fully compatible with Honeywell TDC 3000 / Experion PKS platforms, specific High-Performance Process Manager (HPM) files, and Advanced Process Manager (APM) architectures
• Processor/Chipset: Embedded proprietary architecture for real-time deterministic automation tasks
• Data Throughput: Optimized for microsecond-level synchronization and zero-packet-loss control bus telemetry

Environmental Conditions

• Operating Temperature: 0°C to 60°C (32°F to 140°F)
• Storage Temperature: -40°C to 85°C (-40°F to 185°F)
• Relative Humidity: 5% to 95% (non-condensing)
• Vibration/Shock: Meets industrial standards for cabinet-mounted electronic equipment (IEC compliant)
