IS200SRTDH2ACB

Overview

General Electric IS200SRTDH2ACB DIN‑Rail RTD Terminal Board is part of the Mark VIe control system. It provides RTD signal interfacing through terminal blocks, connector ports, and integrated diode/capacitor assemblies for reliable turbine monitoring.

Basic Information

• Manufacturer: General Electric

• Series: Mark VIe

• Product number: IS200SRTDH2ACB

• Type: DIN‑Rail RTD Terminal Board

Terminal Blocks

• Quantity: 2

• Location: Bottom edge of PCB

• Terminals per block: 18

• Total terminals: 36

Connectors

• Large connector port: For connection to extra components or other boards

Components

• Diodes: 24, black rectangular, arranged in 2 rows of 12

• Capacitors: 1–2 small rectangular capacitors adjacent to each diode

---
