51305943-100

Product Overview

The 51305943-100 is a rugged printed circuit board assembly developed by Honeywell for use in mission‑critical distributed control system environments.

Technical Specifications

Electrical & Power Characteristics

• Input Voltage: Typically 5 V DC or 24 V DC depending on backplane configuration
• Power Consumption: Low-power solid‑state design minimizing enclosure heat load
• Isolation: Integrated galvanic isolation to protect logic circuits from field surges

Environmental Ratings

• Operating Temperature: 0 °C to 60 °C (32 °F to 140 °F)
• Storage Temperature: -40 °C to 85 °C (-40 °F to 185 °F)
• Relative Humidity: 5% to 95% RH, non‑condensing
• Conformal Coating: Available with G3 coating option for harsh environments

Physical Characteristics

• Dimensions: Standard Honeywell module slot form factor
• Weight: Approximately 0.5 kg to 1.0 kg depending on configuration
• Mounting: Plug‑in module with retention screws or latching mechanism

---
