AMM31

Product Overview

The AMM31 from Yokogawa is an advanced measurement module designed to perform high-precision analog signal multiplication for real-time signal processing applications.

Technical Specifications

Core Performance

• Functional Logic: Analog multiplication (Z = X × Y)

• Input Voltage Range (X, Y): ±10 V DC

• Output Voltage Range (Z): ±10 V DC

• Multiplication Accuracy: ±0.5% of full scale (typical)

• Frequency Response: DC to 1 kHz (minimum)

Power & Electrical

• Supply Voltage: ±15 V DC (±5%)

• Isolation Voltage: 2000 V AC (up to 2600 Vrms depending on isolation configuration)

Environmental Conditions

• Operating Temperature Range: 0 to 60°C

• Storage Temperature Range: -10 to 70°C

• Relative Humidity: 5 to 95% RH (non-condensing)

Physical Attributes

• Dimensions (W × H × D): 30 × 130 × 130 mm (approx.)

• Weight: 0.3 kg (approx.)

• Mounting: Rack/slot-mounted module

---
