6GK5108-0BA00-2AC2

Product Overview

6GK5108-0BA00-2AC2 SCALANCE XC108 is an unmanaged industrial Ethernet switch equipped with 8× 10/100 Mbit/s RJ45 ports, LED diagnostics, an error-signaling contact with a set pushbutton, and support for redundant power supply.

Technical Specifications

• Transfer rate: 10/100 Mbit/s
• Network ports: 8× RJ45 electrical connections for network devices
• Signaling contact: 1× 2-pole terminal block, DC 24 V rated, max 0.1 A
• Power supply connection: 1× 4-pole terminal block, DC input
• Supply voltage: 24 V DC rated, operating range 9.6–31.2 V
• Power consumption: Max 0.25 A
• Power loss: 3 W (rated)
• Redundant power supply: Supported
• Input protection: Fuse protection 2.5 A / 125 V
• Operating temperature: -40 to +70 °C
• Storage/transport temperature: -40 to +85 °C
• Relative humidity: Up to 95% (non-condensing at 25 °C)
• Protection class: IP20
• Dimensions (W × H × D): 60 × 147 × 125 mm
• Net weight: 0.475 kg
