6GK5108-0BA00-2AA3

Product Overview

The 6GK5108-0BA00-2AA3 is a SCALANCE X108 unmanaged Industrial Ethernet switch with 8 × 10/100 Mbit/s RJ45 ports, LED diagnostics, fault signal contact, and redundant voltage supply.

Transmission Rate

• Transfer Rate: 10 Mbit/s, 100 Mbit/s

Interfaces

• Electrical Connections (Network): 8 × RJ45 ports
• 100 Mbit/s SC Ports (Multimode): 0

Features

• LED diagnostics
• Fault signal contact
• Set button
• Redundant voltage supply

Ambient Conditions

• Operating Temperature: –20°C to +70°C
• Storage Temperature: –40°C to +80°C
• Transport Temperature: –40°C to +80°C
• Relative Humidity (at 25°C, non‑condensing): 95% max

Physical Specifications

• Protection Class: IP30
• Design: Compact
• Width: 60 mm
• Height: 125 mm
• Depth: 124 mm
• Net Weight: 0.78 kg

---
