6GK5004-1BD00-1AB2

Product Overview

The 6GK5004-1BD00-1AB2 is an unmanaged Industrial Ethernet switch with 4 RJ45 ports and 1 SC port for multimode fiber, supporting 10/100 Mbit/s transmission.

Transmission Rate

• Transfer Rate: 10 Mbit/s, 100 Mbit/s

Interfaces

• Electrical Connections (Network): 4 × RJ45
• 100 Mbit/s SC Ports (Multimode): 1

Power Supply

• Power Connection: 1 × 3‑pole terminal block

Ambient Conditions

• Operating Temperature: –10°C to +60°C
• Storage Temperature: –40°C to +80°C
• Transport Temperature: –40°C to +80°C
• Relative Humidity (at 25°C, non‑condensing): 95% max

Physical Specifications

• Protection Class: IP20
• Design: Box
• Width: 45 mm
• Height: 100 mm
• Depth: 87 mm
• Net Weight: 0.165 kg

Mounting Type

• 35 mm DIN rail mounting: Yes
• Wall mounting: Yes
• S7‑1500 rail mounting: No

---
