51305478-100

Product Overview

The 51305478-100 is a high-performance High-Level Analog Input processor board designed to acquire, condition, and transmit field analog signals within Honeywell’s TDC 3000 and Experion PKS distributed control systems.

Technical Specifications

General Specifications

• System Compatibility: TDC 3000, APM / HPM, Experion PKS

Electrical & Signal Characteristics

• Input Signal Range: 4–20 mA, 1–5 V DC
• Number of Channels: 16
• Power Supply: Via system backplane or dedicated FTA power source
• Isolation: Galvanic isolation between channels and control system

Environmental & Physical Specifications

• Operating Temperature: 0 °C to 60 °C
• Storage Temperature: -40 °C to 85 °C
• Relative Humidity: 5% to 95% (non-condensing)

---
