Product Description

The 51198983-100 is an High-Level Analog Input (HLAI) Board designed for the High-Performance Process Manager (HPM) and Advanced Process Manager (APM) subsystems.

Technical Specifications

• System Compatibility: TDC 3000 / TPS (HPM, APM, EHPM)
• Input Channels: 16 channels (configuration dependent via FTA)
• Signal Input Range: 1–5 VDC or 4–20 mA (via external shunt resistors)
• A/D Conversion Resolution: 12-bit to 16-bit (system dependent)
• Common Mode Rejection: >60 dB at 50/60 Hz
• Isolation Voltage: 500 VDC channel-to-system
• Power Requirements: +5 VDC and +24 VDC via backplane
• Operating Temperature: 0°C to 60°C
• Storage Temperature: -40°C to 85°C
• Relative Humidity: 5%–95% non-condensing
