2MLF-AV8A

Product Overview

The 2MLF-AV8A from Honeywell is an analog input module designed to acquire high-speed multi-channel analog signals for PLC-based control systems.

Technical Specifications

Maximum conversion speed: 250µs/channel

Absolute maximum input: ±15V

Analog input channels: 8 channels/module

Isolation method: Photo-coupler isolation between input terminal and PLC power (no isolation between channels)

Terminal connected: 18-point terminal

I/O addresses assigned: Fixed type 64 points, Variable type 16 points

Internal-consumed current: DC 5V: 420mA

Weight: 0.14 kg

---
