1606-XLS960EE

Overview

1606-XLS960EE Allen-Bradley XL Power Supply is a high-performance DIN rail-mounted unit delivering regulated 24 VDC output at up to 40 A continuous, designed for heavy-duty industrial automation systems requiring maximum efficiency and reliability.

Output Characteristics

• Nominal Output Voltage: 24 V DC (adjustable 24–28 V DC)

• Continuous Output Current: 40–34.3 A

• Short-Term Output (4 s): 60–51.5 A

• Continuous Output Power: 960 W

• Short-Term Output Power (4 s): 1440 W

• Ripple Voltage: ≤ 100 mVpp (20 Hz–20 MHz bandwidth)

Input Ratings

• AC Input Voltage: 200–240 V AC (-15% / +10%)

• Mains Frequency: 50–60 Hz ±6%

• AC Input Current: 4.6 A @ 230 V AC

• Power Factor: 0.96 @ 230 V AC

• AC Inrush Current: ~14 A peak @ 230 V AC

Performance Characteristics

• Efficiency (typical): 94.6% @ 230 V AC

• Losses (typical): 54.8 W @ 230 V AC

• Hold-up Time: ~30 ms @ 230 V AC

• Operating Temperature Range: -25 °C to +70 °C

• Derating: 24 W/°C from +60 °C to +70 °C

Mechanical Ratings

• Dimensions (W × H × D): 125 × 124 × 127 mm

• Weight: 1800 g (3.97 lb)

• Mounting: DIN rail

---
