TK-FXX132

Product Description

The TK-FXX132 is an industrial-grade fiber optic media converter designed to extend Ethernet networks in demanding industrial environments. It enables reliable and secure data transmission between copper and fiber segments, supporting long-distance communication while ensuring robust performance.
Technical Specifications

Transmission Distance

• Multimode: Up to 2 km

• Single-mode: Up to 80 km

Fiber Type

• Multimode: 62.5/125 μm, 50/125 μm

• Single-mode: 9/125 μm

Wavelength

• Multimode: 850 nm

• Single-mode: 1310 nm or 1550 nm

Data Rate：10/100/1000 Mbps (Fast/Gigabit Ethernet)

Operating Temperature：-40°C to +85°C

Humidity：5% to 95% RH (non-condensing)

Dimensions (HxWxD)：44.5 × 120 × 100 mm

Weight：300 g

Compliance：CE, UL, ATEX, IECEx

Vibration Resistance：2 g, 10–500 Hz

Shock Resistance：30 g, 11 ms

Mounting：DIN rail

Power Supply：24 VDC (18–30 VDC range)

Power Consumption：Max 5.0 W

Environmental Protection：IP20

MTBF：100,000 hours

---
