TC-KIOL1

Product Overview

The TC-KIOL10 is a high-performance optical isolator used to protect sensitive components in fiber optic communication systems and laser applications.

Technical Specifications

• Function: Allows light to travel in one direction, preventing back-reflections

• Optical Isolation: Peak isolation ≥ 40 dB (Single Stage), ≥ 55 dB (Dual Stage)

• Insertion Loss: 0.3–0.5 dB typical

• Polarization Dependent Loss (PDL): ≤ 0.1 dB

• Return Loss: ≥ 50–55 dB

• Power Handling: 300–500 mW standard; high-power versions up to 10 W

• Center Wavelength: 1030, 1064, or 1550 nm

• Operating Bandwidth: ±5 to ±20 nm

• Polarization Mode Dispersion: ≤ 0.2 ps

• Operating Temperature: -5 to +70 °C

• Storage Temperature: -40 to +85 °C
